Controlled squeegee motion
A servo drive operates the squeegee movement in the published design.
APL / 42
APPLICATION-LED ENGINEERING01 / 01
Glass finishing
Four Pillar Glass Screen Printer
Large surfaces. A coordinated print cycle.
Four pillar automatic screen printing with pre-centering and inbuilt positioning.
Configured around your material, process and production needs.
- Squeegee drive
- Servo
- Bed options
- Fixed / sliding
- Integration
- Glass centring & dryer
The technology, explained
Large surfaces. A coordinated print cycle.
01 — OVERVIEWThe Four Pillar Screen Printing Machine is presented for large glass, wood, sunboard and vinyl applications. It uses a servo-driven squeegee and a jack-screw screen lift, with an AC induction drive for the peel-off arrangement.
Fixed-bed and sliding-bed versions are described. For glass lines, optional pre-centring can receive material from a washer or manual loading, then coordinate printing and transfer toward the dryer. Confirm the bed format and handling options around the sheet dimensions and the intended production layout.
Inside the machine
Designed around
the details.
Explore the capabilities that shape this machine’s role on your production floor.
Pillar lift arrangement
A jack-screw mechanism lifts the screen within the four-pillar structure.
Bed configuration
Discuss fixed and sliding-bed variants against the required handling method.
Optional pre-centring
A sensor and servo arrangement can coordinate glass received from a washer or manual loading.
Product configuration
| Configuration detail | Published product profile |
|---|---|
| Squeegee drive | Servo |
| Bed options | Fixed / sliding |
| Integration | Glass centring & dryer |
Published output figures refer to reference configurations. Actual results depend on material, artwork, process settings and selected options.
THE MATERIAL IS THE STARTING POINTApplication possibilities
Where this
technology fits.
- Large glass panels
- Wood surface printing
- Sunboard and vinyl graphics
Material study shown for illustration. Discuss the actual substrate and intended finish with APL.
Plan your next step
A better brief.
A better fit.
Bring these details to your first conversation with the APL team.
- 01Glass dimensions, thickness and sheet handling
- 02Ink or coating system and intended end use
- 03Printing sequence, drying requirements and line layout
